Technical Specification

Processor:AMD Ryzen 7 7435HS (8C / 16T, 3.1 / 4.5GHz, 4MB L2 / 16MB L3)

Graphics: NVIDIA® GeForce RTX 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 105W

Chipset: AMD SoC Platform

Memory: 12GB SO-DIMM DDR5-4800

Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory: Up to 32GB DDR5-4800

Storage: 512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®

Storage:Support Up to two drives, 2x M.2 SSD  M.2 2242 SSD up to 1TB

Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots

Card Reader: None

Optical None

Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers: Stereo speakers, 2W x2, optimized with Nahimic Audio

Camera: HD 720p with E-shutter

Microphone: 2x, Array

Battery: Integrated 60Wh

Max Battery Life –

Power Adapter: 170W Slim Tip (3-pin)

Special Features: AI Chip: LA1

DESIGN

Display: 15.6″ FHD (1920×1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®

Touchscreen: None

Color Calibration: None

Keyboard: White Backlit, English

Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Case Color: Luna Grey

Surface Treatment: Painting

Case Material: PC-ABS (Top), PC-ABS (Bottom)

Dimensions (WxDxH) 359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)

Weight Starting at 2.38 kg (5.25 lbs)

SOFTWARE

Operating System: Windows® 11 Home Single Language, English

Bundled Software: Office Home & Student 2021

CONNECTIVITY

Ethernet: 100/1000M (RJ-45)

WLAN + Bluetooth: Wi-Fi® 6, 802.11ax 2×2 + BT5.2

Standard Ports

3x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort? 1.4

1x HDMI® 2.1, up to 8K/60Hz

1x Headphone / microphone combo jack (3.5mm)

1x Ethernet (RJ-45)

1x Power connector

Docking Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for LOQ 15ARP9

Security ChipFirmware TPM 2.0 Enabled

Fingerprint Reader:None

Other Security E-shutter

SERVICE

Base Warranty 1-year, Courier or Carry-in

Upgrade 2Y Premium Care -IPENTRY (ESS)

ACCESSORIES

Bundled Accessories: None

CERTIFICATIONS

Green Certifications ErP lot 3

RoHS compliant

Other Certifications ÜV Rheinland® Low Blue Light (Software Solution)

Mil-Spec Test
