Description

Technical Specifications:

Processor Intel® Core i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 / 5.5GHz, E-core 1.5 / 3.9GHz, 33MB

Graphics NVIDIA® GeForce RTX 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS

Chipset Intel® HM770 Chipset

Memory 1x 16GB SO-DIMM DDR5-5600

Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory Up to 32GB DDR5-5600 offering

Storage 1TB SSD M.2 2242 PCIe® 4.0×4 NVMe®

Storage Support Up to two drives, 2x M.2 SSD M.2 2242 SSD up to 1TB each

Storage Slot Two M.2 2280 PCIe® 4.0 x4 slots

Card Reader None

Optical None

Audio Chip High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio

Camera 5.0MP with E-shutter

Microphone 2x, Array

Battery 80Wh

Power Adapter 245W Slim Tip (3-pin)

Special Features AI Chip: LA1

DESIGN

Display 15.1″ WQXGA (2560×1600) OLED 500nits glossy, 100% DCI-P3, 165Hz, Dolby Vision®, DisplayHDR? True Black 600

Touchscreen None

Color Calibration Factory Color Calibration

Keyboard 24-Zone RGB Backlit, English

Touchpad Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Case Color Eclipse Black

Surface Treatment Aluminium Stamping (Anodized with Sandblasting)

Case Material Aluminium (Top), PC-ABS + 15% Talc (Bottom)

Pen Pen Not Supported

Dimensions (WxDxH) 344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79- 0.85 inches)

Weight Starting at 1.9 kg (4.19 lbs)

SOFTWARE

Operating System Windows® 11 Home Single Language, English

Bundled Software Office Home 2024 + Lenovo® AI Now

CONNECTIVITY

WLAN + Bluetooth Wi-Fi® 7, 802.11be 2×2 + BT5.4

WWAN Non-WWAN

Ethernet 100/1000M (RJ-45)

Standard Ports 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)

– 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On

– 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort? 2.1

– 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort? 1.4

– 1x HDMI® 2.1, up to 8K/60Hz

– 1x Headphone / microphone combo jack (3.5mm)

– 1x Ethernet (RJ-45)

– 1x Power connector

Docking Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 15IRX10

SECURITY & PRIVACY

Security Chip Firmware TPM 2.0 Enabled

Fingerprint Reader None

Other Security E-shutter

SERVICE

Base Warranty 1-year, Courier or Carry-in

Included Warranty Upgrade 3Y Legion Ultimate Support -IPMAIN (ESS)

ACCESSORIES

Bundled Accessories None

CERTIFICATIONS

Green Certifications ErP Lot 6/26

– RoHS compliant

Other Certifications TÜV Rheinland® Flicker Free

– TÜV Rheinland® High Gaming Performance

TÜV Rheinland® Low Blue Light (Hardware Solution)
